01 |
PFQ531726083 |
夹线螺钉 Screw |
1 |
0 |
|
|
02 |
PFQ512 |
面板垫FACE PLATE GASKET |
1 |
1.83 |
|
|
03 |
PF5550824 |
油窗OIL WINDOW |
1 |
0.56 |
|
|
04 |
PF5550825 |
油窗O型圈THRUST COLLAR ASM |
1 |
0.10 |
|
|
05 |
PF5550113 |
挑线连杆销螺孔塞RUBBER PLUG |
3 |
0.12 |
|
|
06 |
PF5550112 |
针杆曲柄螺孔塞RUBBER PLUG |
2 |
0.18 |
|
|
07 |
PF555016 |
后窗板螺钉SCREW 3/16X28 L=9 |
8 |
0.06 |
|
|
08 |
PFQ518 |
后窗板SIDE PLATE |
1 |
11.02 |
|
|
09 |
PFQ519 |
后窗板垫SIDE PLATE GASKET |
1 |
4.02 |
|
|
10 |
PFQ5110 |
三眼线勾THREE EYELINER HOOK |
1 |
0.93 |
|
|
11 |
PF5550114 |
送料调节器孔塞RUBBER PLUG |
1 |
0.22 |
|
|
12 |
PF5550115 |
下轴盲孔塞RUBBER PLUG |
1 |
0.28 |
|
|
13 |
PFS1T0113 |
型号牌MODEL PLATE |
1 |
0 |
|
|
14 |
PF555013 |
底板支柱BED SCREW STUD |
4 |
0.75 |
|
|
16 |
PF99901511 |
电线压板（短）CORD HOLDER(S) |
2 |
0.36 |
|
|
17 |
PF5550161 |
电线压板固定螺钉SCREW 3/16X28 L=12 |
3 |
0.10 |
|
|
18 |
PF99901160 |
电线压板（长）CORD HOLDER(L) |
1 |
0.38 |
|
|
21 |
PFQ1121 |
型号牌铆钉POLE |
2 |
0 |
|
|
22 |
PF90000131 |
绕线器紧固定螺钉SCREW 3/16X32 L=7 |
3 |
0.33 |
|
|
23 |
PF90000132 |
绕线切刀THREAD CUTTER |
1 |
1.00 |
|
|
24 |
PF68425K19 |
绕线切刀固定螺钉SCREW 1/8X40 L=4 |
2 |
0.10 |
|
|
25 |
PF5550230 |
挑线杆护罩螺钉SCREW 3/16X28 L=6 |
1 |
0.10 |
|
|
26 |
PF5550229 |
挑线杆护罩THREAD TAKE-UP LEVER COVER |
1 |
0.56 |
|
|
27 |
PF5550316 |
右线钩RIGHT ARM THREAD GUIDE |
1 |
0.36 |
|
|
28 |
PF5550317 |
右线钩螺钉SCREW 11/64X40 L=6 |
3 |
0.10 |
|
|
29 |
PF9520MXDK021 |
大线钩LARGE ARM THREAD GUIDE |
1 |
0.98 |
|
|
31 |
PF5550637 |
针板螺钉SCREW 11/64X40 L=8.5 |
2 |
0.10 |
|
|
32 |
PFQ50132 |
卷边器座RULER PLATE |
1 |
1.14 |
|
|
33 |
PF5550117 |
卷边器座螺钉SCREW 11/64X40 L=5 |
2 |
0.10 |
|
|
34 |
PF5550638 |
推板组件SLIDE PLATE ASM |
1 |
2.14 |
|
|
35 |
PF555063801 |
推板SLIDE PLATE |
1 |
0 |
|
|
36 |
PF555063802 |
推板簧SPRING OF SLIDE PLATE |
1 |
0 |
|
|
37 |
PF555063803 |
推板螺钉SCREW |
2 |
0 |
|
|
38 |
PF5550161 |
面板螺钉 SCREW 3/16X28 L=12 |
3 |
0.10 |
|
|
39 |
PF5550111 |
面板调节螺孔塞RUBBER PLUG |
2 |
0.13 |
|
|
40 |
PFQ50140 |
面板装饰牌PLATE |
1 |
0 |
|
|
41 |
PFQ5141 |
绕线夹线器组件BOBBIN THREAD TENSION ASM |
1 |
3.23 |
|
|
42 |
PF90000157 |
绕线器BOBBIN WINDER ASM |
1 |
12.44 |
|
|
42-1 |
PF900001511 |
绕线器油封OIL SEAL |
1 |
1.04 |
|
|
43 |
PFQ1139 |
安全指示牌SAFETY-INDICATING PLATE |
1 |
0 |
|
|
44 |
PFQ1190 |
电机罩组件PILLEY COVER ASM |
1 |
0 |
|
|
45 |
PFQ50145 |
电机罩组件固定螺钉SCREW M4 L=20 |
3 |
0.20 |
|
|
46 |
PFQ50146 |
电机罩组件固定螺钉垫片WASHER |
3 |
0 |
|
|
49 |
PFQ5149 |
支架固定螺钉SCREW M4 L=5.5 |
2 |
0.10 |
|
|
50 |
PFQ5150 |
支架 STAND |
1 |
0.39 |
|
|
51 |
PFQ5151 |
操作面板顶紧螺钉SCREW M5 L=25 |
1 |
0 |
|
|
53 |
PF98000187 |
调节孔孔塞RUBBER PLUG |
1 |
0.31 |
|
|
54 |
PFQ5129 |
左线钩LEFT ARM THREAD GUIDE |
1 |
1.49 |
|
|
56 |
PF9520MXDK02101 |
螺母 NUT 11/64X40 |
1 |
0 |
|
|
57 |
PF1310D239 |
地线紧固螺钉SCREW M4 |
1 |
0.17 |
|
|
58 |
PF68425H33 |
二眼线钩螺钉SCREW |
1 |
0.16 |
|
|
59 |
PF5550314 |
二眼线钩TWO-HOLE THREAD EYELET |
1 |
0.58 |
|
|
60 |
PF5550330 |
夹线器螺钉SCREW |
1 |
0.10 |
|
|
61-1 |
PFQ531726 |
夹线器组件THREAD TENSION ASM |
1 |
4.15 |
|
|
62 |
PF5550330 |
松线钉THREAD RELEASE PIN |
1 |
0.10 |
|
|
63 |
PF5550334 |
松线辅钉弹簧TESNION RELEASE PIN SPRING |
1 |
0.10 |
|
|
64 |
PFQ10153 |
垫片WASHER |
1 |
0 |
|
|
65 |
PF5550333 |
卡圈 E-RING |
1 |
0.10 |
|
|
66 |
PF90000329 |
松线辅钉 TESNION RELEASE SUPPORTING PIN |
1 |
0.45 |
|
|
30-2 |
PF0302141 |
针板 M2.6NEEDLE PLATE |
1 |
2.59 |
|
|
61-2 |
PFQ5H3172601 |
厚料大夹线器组件THREAD TENSION ASM |
1 |
4.15 |
|
|
68-1 |
PFQ53172606 |
夹线簧 Clamp spring |
1 |
0 |
|
|
68-2 |
PFQ5H3172606 |
夹线簧（厚料）Clamp spring Heavy |
1 |
0 |
|
|
69-1 |
PFQ53172606 |
挑线簧 Take up spring |
1 |
0 |
|
|
69-2 |
PFQ5H3172606 |
挑线簧 （厚料）Take up spring Heavy |
1 |
0 |
|
|
70 |
PFQ53172608 |
夹线螺母 Tension Nut |
1 |
0 |
|
|
71 |
PFQ53172605 |
松线板 Tension Disc Holder |
1 |
0 |
|
|
72 |
PFQ53172604 |
夹线板 Tension Disc |
1 |
0 |
|
|
73 |
PFQ531726083 |
夹线螺钉 Screw |
1 |
0 |
|
|
30-3 |
PF90010140H |
针板 M2.4NEEDLE PLATE |
1 |
2.07 |
|
|
30-1 |
PF5550636 |
针板 M1.9NEEDLE PLATE |
1 |
2.42 |
